Page 11 - Olipes Industrial Maintenance

Multipliers • Motor variators • Gear motors • Gearboxes • Open gears in watertight casing

Low environmental impact

MAXIGEAR BBO

100% synthetic Ester-base biodegradable oils for the
lubrication of industrial gears subjected to high pressures
and high levels of torque, gearboxes, multipliers, mechanical
variators, worm screws, planetary gears, hypoid and chain
gears. Also recommended as biodegradable circulation oils
for gears and bushings. These oils feature extreme pressure,
anti-wear, anti-rust, and anti-corrosion properties and are
reinforced with unctuousness agents which considerably
improve their lubricant properties in comparison with
traditional oils.
They stand out due to their high degree of biodegradability
(over 80% in the CEC-L-33-A-93 test)*, excellent heat stability
and long service life, thereby minimising costs in relation to
stoppages and maintenance .
(1)
AGMA 9005-D94EP DIN 51517/3-CLP ISO 3498-CKC CEC L-33-A-93
* In accordance with the degree of viscosity

High temperatures and high loads

OLIOL
High-performance polyglycol-based synthetic oils for the lubrication of compressors,
bearings and gears with a high resistance to seizure and anti-wear protection. OLIOL
oils feature a natural high viscosity index (V.I.) , low friction coefficient, low freezing
point, excellent heat and oxidation stability, low to zero formation of carbon residue,
compatibility with most sealing elastomers (2), good heat conductivity (ensuring rapid
heat dissipation) and good shearing stability and they are ideal for the transportation
of loads.
AGMA 9005-D94EP DIN 51517/3-CLP ISO 3498-CKC US STEEL:224
HIGH
TEMPERATURES

(1) MAXIGEAR BBO oils are miscible with others used for the same purposes and with identical levels of quality. It is advisable to check the
state of the other oil and the system in question prior to mixing. Check the joints and seals are suitable for this type of lubricant (NBR nitrile
rubber, Chloroprene, Viton® FPM fluoro rubber, EPDM butyl rubber.
(2) OLIOL: Depending on the weather and the temperature, polyglycol synthetic based oils may attack elastomers. At constant
temperatures of up to100º C NBR-type rubber joints (acrylonitrile- butadiene rubber) may be used, or even SBR. For higher temperatures we
recommend the use of FKM-based watertight materials (fluoro rubber), VMQ (vinyl methyl silicone), SBM and SILICONE (which withstand
peaks of up to 250º C), among others. VITON (black fluoroelastomer which withstands temperature peaks of up to 300º C) joints are
recommended in the event of the considerable loss of lubricant due to misalignments, as the use of this type of oil as a lubricant may result
in the volume of these joints increasing by up to 7.95%, thereby reducing such lubricant loss (test method for the determination of the %
change in volume based on ASTM D-471 for 166 hours at 70º C, ±2º C).
We recommended the use of epoxy resin coatings or epoxy phenolic paint on parts which come into contact with the lubricant, given the
natural tendency of polyglycols to soften and sometimes strip paints and coatings. The level windows should be made of natural glass or
polyamide-based materials, as other transparent plastic materials such as plexiglass might crack. Not compatible with mineral oils.

9
